Toz Keçeleri
K103
Nutring Dudaklı Toz Keçesi
- Malzeme
- PU NBR
- Kodu
- PU9201 NB9001
- Sıcaklık (max) °C
- -40/+100 -30/+105
- Kayma Hızı (max)- m/s
- 1.0
Avantajları
- Mil üzerinde yağ filmini optimize eden radyuslu dudak yapısı
- Kanal içinde dönmeme özelliği
- Poliüretan malzemenin yüksek yırtılma ve kopma mukavemeti sayesinde ağır şartlarda kullanıma uygun olması
- Kolay montaj yapılabilmesi
Uygulama Alanları
- Forkliftler
- Araç üstü sektörü
- Endüstriyel silindirler
- Enjeksiyon makineleri
Teknik Çizim
Ölçü Tablosu
45 ölçü · Kod veya ölçü ile filtreleyin
45 sonuç
| Kod | d (f8) | D (+0/-0.2) | D1 (H10) | L (+0.2/-0) | L1 | H | MALZEME | KASTAŞ KOD | |
|---|---|---|---|---|---|---|---|---|---|
| K103-014 | 14 | 22 | 18.3 | 5 | 7 | 6 | NB9001 | 10001912 | — |
| K103-016 | 16 | 24 | 20.3 | 5 | 7 | 6 | NB9001 | 10001913 | — |
| K103-018 | 18 | 26 | 22.3 | 5 | 7 | 6 | NB9001 | 10001914 | — |
| K103-018 PU | 18 | 26 | 22.3 | 5 | 7 | 6 | PU9201 | 10001916 | — |
| K103-020 | 20 | 28 | 24.3 | 5 | 7 | 6 | NB9001 | 10001917 | — |
| K103-020 PU | 20 | 28 | 24.3 | 5 | 7 | 6 | PU9201 | 10001919 | — |
| K103-022 | 22 | 30 | 26.3 | 5 | 7 | 6 | NB9001 | 10001920 | — |
| K103-025 | 25 | 33 | 29.3 | 5 | 7 | 6 | NB9001 | 10001923 | — |
| K103-025 PU | 25 | 33 | 29.3 | 5 | 7 | 6 | PU9201 | 10001925 | — |
| K103-028 | 28 | 36 | 32.3 | 5 | 7 | 6 | NB9001 | 10001927 | — |
| K103-028 PU | 28 | 36 | 32.3 | 5 | 7 | 6 | PU9201 | 10001929 | — |
| K103-030 | 30 | 38 | 34 | 6 | 8 | 6.5 | NB9001 | 10001930 | — |
| K103-030 PU | 30 | 38 | 34 | 6 | 8 | 6.5 | PU9201 | 10001931 | — |
| K103-031 PU | 31.5 | 39.5 | 35.5 | 6 | 8 | 6.5 | PU9201 | 10001932 | — |
| K103-032 PU | 32 | 40 | 36 | 6 | 8 | 6.5 | PU9201 | 10001933 | — |
| K103-035 | 35 | 43 | 39 | 6 | 8 | 6.5 | NB9001 | 10001934 | — |
| K103-035 PU | 35 | 43 | 39 | 6 | 8 | 6.5 | PU9201 | 10001936 | — |
| K103-040 | 40 | 48 | 44 | 6 | 8 | 6.5 | NB9001 | 10001940 | — |
| K103-040 PU | 40 | 48 | 44 | 6 | 8 | 6.5 | PU9201 | 10001941 | — |
| K103-045 | 45 | 53 | 49 | 6 | 8 | 6.5 | NB9001 | 10001943 | — |
| K103-045 PU | 45 | 53 | 49 | 6 | 8 | 6.5 | PU9201 | 10001945 | — |
| K103-050 | 50 | 58 | 54 | 6 | 8 | 6.5 | NB9001 | 10001947 | — |
| K103-050 PU | 50 | 58 | 54 | 6 | 8 | 6.5 | PU9201 | 10001948 | — |
| K103-055 | 55 | 63 | 59 | 6 | 8 | 6.5 | NB9001 | 10001949 | — |
| K103-055 PU | 55 | 63 | 59 | 6 | 8 | 6.5 | PU9201 | 10001951 | — |
| K103-060 | 60 | 68 | 64 | 6 | 8 | 6.5 | NB9001 | 10001952 | — |
| K103-060 PU | 60 | 68 | 64 | 6 | 8 | 6.5 | PU9201 | 10001953 | — |
| K103-070 | 70 | 80 | 75 | 7 | 10 | 8 | NB9001 | 10001957 | — |
| K103-070 PU | 70 | 80 | 75 | 7 | 10 | 8 | PU9201 | 10001959 | — |
| K103-075 | 75 | 85 | 80 | 7 | 10 | 8 | NB9001 | 10001961 | — |
| K103-075 PU | 75 | 85 | 80 | 7 | 10 | 8 | PU9201 | 10001962 | — |
| K103-080 | 80 | 90 | 85 | 7 | 10 | 8 | NB9001 | 10001963 | — |
| K103-080 PU | 80 | 90 | 85 | 7 | 10 | 8 | PU9201 | 10001964 | — |
| K103-085 PU | 85 | 95 | 90 | 7 | 10 | 8 | PU9201 | 10001965 | — |
| K103-090 | 90 | 100 | 95 | 7 | 10 | 8 | NB9001 | 10001966 | — |
| K103-090 PU | 90 | 100 | 95 | 7 | 10 | 8 | PU9201 | 10001967 | — |
| K103-095 PU | 95 | 105 | 100 | 7 | 10 | 8 | PU9201 | 10001968 | — |
| K103-100 | 100 | 110 | 105 | 7 | 10 | 8 | NB9001 | 10001970 | — |
| K103-100 PU | 100 | 110 | 105 | 7 | 10 | 8 | PU9201 | 10001971 | — |
| K103-110 PU | 110 | 120 | 115 | 7 | 10 | 8 | PU9201 | 10001972 | — |
| K103-125 PU | 125 | 138 | 132 | 8 | 11 | 9.5 | PU9201 | 10001974 | — |
| K103-140 PU | 140 | 153 | 147 | 8 | 11 | 9.5 | PU9201 | 10001976 | — |
| K103-150 PU | 150 | 163 | 157 | 8 | 11 | 9.5 | PU9201 | 10001978 | — |
| K103-180 PU | 180 | 193 | 187 | 8 | 11 | 9.5 | PU9201 | 10001979 | — |
| K103-200 PU | 200 | 213 | 207 | 8 | 11 | 9.5 | PU9201 | 10001983 | — |
