Toz Keçeleri
K27
Nutring Dudaklı Toz Keçesi
- Malzeme
- PU NBR
- Kodu
- PU9201 NB9001
- Sıcaklık (max) °C
- -40/+100 -30/+105
- Kayma Hızı (max)- m/s
- 1.0
Avantajları
- Özel tasarımı sayesinde olumsuz partiküllere karşı üstün koruma sağlaması
- Nutring dudaklı tasarımı ile mil üzerindeki yağ filmini sıyırma özelliği
- Kanal içinde dönmeme özelliği
- Yağ filmi kalınlığının incelmesini sağlayan kesimli nutring dudağı
- Kolay montaj yapılabilmesi
Uygulama Alanları
- Forkliftler
- İş makineleri sektörü
- Enjeksiyon tezgahları
- Tarım sektörü
- Genel endüstriyel silindirler
Teknik Çizim
Ölçü Tablosu
148 ölçü · Kod veya ölçü ile filtreleyin
148 sonuç
| Kod | d (f8) | D (H10) | D1 (H10) | L (+0.2/-0) | L1 | H | MALZEME | KASTAŞ KOD | |
|---|---|---|---|---|---|---|---|---|---|
| K27-008 | 8 | 14 | 11.2 | 4.3 | 6.3 | 5.5 | NB9001 | 10014689 | — |
| K27-012/1 | 0.502 | 0.804 | 0.615 | 0.2 | 0.278 | 0.236 | NB9001 | 10014695 | — |
| K27-010 PU | 10 | 16.1 | 12.7 | 3.9 | 5.9 | 4.8 | PU9201 | 10014691 | — |
| K27-012/1 PU | 0.502 | 0.804 | 0.615 | 0.2 | 0.278 | 0.236 | PU9201 | 10014696 | — |
| K27-010/1 PU | 10 | 15 | 12 | 5 | 7 | 6 | PU9201 | 10014692 | — |
| K27-015 | 0.627 | 0.929 | 0.74 | 0.2 | 0.278 | 0.236 | NB9001 | 10014702 | — |
| K27-012 | 12 | 18 | 14.6 | 3.6 | 5.6 | 4.8 | NB9001 | 10014693 | — |
| K27-015 PU | 0.627 | 0.929 | 0.74 | 0.2 | 0.278 | 0.236 | PU9201 | 10014703 | — |
| K27-015/1 | 0.625 | 0.937 | 0.752 | 0.201 | 0.28 | 0.236 | NB9001 | 10014704 | — |
| K27-015/1 PU | 0.625 | 0.937 | 0.752 | 0.201 | 0.28 | 0.236 | PU9201 | 10014705 | — |
| K27-013 | 13 | 20 | 16 | 5.8 | 7.8 | 7.3 | NB9001 | 10014697 | — |
| K27-025/1 | 1.002 | 1.367 | 1.131 | 0.215 | 0.293 | 0.264 | NB9001 | 10014738 | — |
| K27-014 | 14 | 20 | 16.5 | 3.6 | 5.6 | 4.8 | NB9001 | 10014698 | — |
| K27-025/1 PU | 1.002 | 1.367 | 1.131 | 0.215 | 0.293 | 0.264 | PU9201 | 10014739 | — |
| K27-014/1 PU | 14 | 20 | 16.5 | 4 | 6 | 6 | PU9201 | 10014700 | — |
| K27-034 | 1.375 | 1.75 | 1.502 | 0.215 | 0.293 | 0.264 | NB9001 | 10014757 | — |
| K27-034 PU | 1.375 | 1.75 | 1.502 | 0.215 | 0.293 | 0.264 | PU9201 | 10014759 | — |
| K27-044 | 1.752 | 2.117 | 1.881 | 0.213 | 0.291 | 0.264 | NB9001 | 10014779 | — |
| K27-044 PU | 1.752 | 2.117 | 1.881 | 0.213 | 0.291 | 0.264 | PU9201 | 10014782 | — |
| K27-050/4 | 2.002 | 2.367 | 2.131 | 0.215 | 0.293 | 0.264 | NB9001 | 10014805 | — |
| K27-016 | 16 | 22 | 19 | 3.8 | 5.8 | 5.5 | NB9001 | 10014706 | — |
| K27-050/4 PU | 2.002 | 2.367 | 2.131 | 0.215 | 0.293 | 0.264 | PU9201 | 10014807 | — |
| K27-016 PU | 16 | 22 | 19 | 3.8 | 5.8 | 5.5 | PU9201 | 10014708 | — |
| K27-053 | 2.125 | 2.5 | 2.272 | 0.222 | 0.301 | 0.293 | NB9001 | 10014809 | — |
| K27-016/1 | 16 | 24 | 19 | 4.3 | 6.3 | 6 | NB9001 | 10014709 | — |
| K27-060/3 PU | 2.374 | 2.713 | 2.492 | 0.236 | 0.315 | 0.343 | PU9201 | 10014827 | — |
| K27-016/2 PU | 16 | 22 | 18.5 | 3.9 | 5.9 | 4.8 | PU9201 | 10014712 | — |
| K27-063/2 | 2.503 | 2.997 | 2.635 | 0.276 | 0.354 | 0.341 | NB9001 | 10014834 | — |
| K27-018/2 | 18 | 24.6 | 21 | 3.8 | 5.8 | 4.8 | NB9001 | 10014715 | — |
| K27-076 | 3 | 3.5 | 3.248 | 0.278 | 0.356 | 0.341 | NB9001 | 10014850 | — |
| K27-018/4 PU | 18 | 26.6 | 21 | 5.3 | 7.3 | 7 | PU9201 | 10014719 | — |
| K27-088 | 3.503 | 3.997 | 3.63 | 0.276 | 0.354 | 0.341 | NB9001 | 10014858 | — |
| K27-020 | 20 | 28.6 | 23 | 5.3 | 7.3 | 7 | NB9001 | 10014720 | — |
| K27-101 | 4.003 | 4.497 | 4.135 | 0.278 | 0.356 | 0.341 | NB9001 | 10014873 | — |
| K27-020 PU | 20 | 28.6 | 23 | 5.3 | 7.3 | 7 | PU9201 | 10014722 | — |
| K27-127 | 5 | 5.5 | 5.209 | 0.278 | 0.356 | 0.341 | NB9001 | 10014887 | — |
| K27-020/2 PU | 20 | 26 | 22.5 | 4 | 6 | 5 | PU9201 | 10014725 | — |
| K27-139 | 5.5 | 6 | 5.709 | 0.278 | 0.356 | 0.341 | NB9001 | 10014892 | — |
| K27-022 | 22 | 28 | 25 | 3.9 | 5.9 | 5 | NB9001 | 10014727 | — |
| K27-022 PU | 22 | 28 | 25 | 3.9 | 5.9 | 5 | PU9201 | 10014729 | — |
| K27-022/1 | 22 | 30 | 25.2 | 5.3 | 7.3 | 7 | NB9001 | 10014730 | — |
| K27-022/1 PU | 22 | 30 | 25.2 | 5.3 | 7.3 | 7 | PU9201 | 10014732 | — |
| K27-022/3 PU | 22 | 28 | 24.5 | 4 | 6 | 5.7 | PU9201 | 10014734 | — |
| K27-025 | 25 | 33.6 | 28 | 5.3 | 7.3 | 7 | NB9001 | 10014735 | — |
| K27-025 PU | 25 | 33.6 | 28 | 5.3 | 7.3 | 7 | PU9201 | 10014737 | — |
| K27-025/2 PU | 25 | 31 | 27.5 | 3.9 | 5.9 | 4.8 | PU9201 | 10014741 | — |
| K27-028 | 28 | 36.6 | 31 | 5.3 | 7.3 | 7 | NB9001 | 10014742 | — |
| K27-028 PU | 28 | 36.6 | 31 | 5.3 | 7.3 | 7 | PU9201 | 10014744 | — |
| K27-028/1 | 28 | 36 | 31.2 | 4.8 | 6.8 | 5.8 | NB9001 | 10014745 | — |
| K27-030 | 30 | 38.6 | 33 | 5.3 | 7.3 | 7 | NB9001 | 10014749 | — |
| K27-030 PU | 30 | 38.6 | 33 | 5.3 | 7.3 | 7 | PU9201 | 10014751 | — |
| K27-031.5 PU | 31.5 | 41.5 | 34.7 | 5.3 | 7.3 | 7 | PU9201 | 10014754 | — |
| K27-032 PU | 32 | 40 | 35.2 | 5.3 | 7.3 | 7 | PU9201 | 10014755 | — |
| K27-032/1 PU | 32 | 40 | 35.2 | 4.8 | 6.8 | 5.8 | PU9201 | 10014756 | — |
| K27-035 | 35 | 43.6 | 38 | 5.3 | 7.3 | 7 | NB9001 | 10014760 | — |
| K27-035 PU | 35 | 43.6 | 38 | 5.3 | 7.3 | 7 | PU9201 | 10014762 | — |
| K27-035/1 PU | 35 | 45 | 38.2 | 6.3 | 8.3 | 8 | PU9201 | 10014763 | — |
| K27-036 | 36 | 44.6 | 39 | 5.3 | 7.3 | 7 | NB9001 | 10014764 | — |
| K27-036 PU | 36 | 44.6 | 39 | 5.3 | 7.3 | 7 | PU9201 | 10014766 | — |
| K27-038 | 38 | 48 | 41.6 | 4.3 | 6.3 | 5.8 | NB9001 | 10014770 | — |
| K27-038 PU | 38 | 48 | 41.6 | 4.3 | 6.3 | 5.8 | PU9201 | 10014771 | — |
| K27-040 | 40 | 48.6 | 43 | 5.3 | 7.3 | 7 | NB9001 | 10014772 | — |
| K27-040 PU | 40 | 48.6 | 43 | 5.3 | 7.3 | 7 | PU9201 | 10014775 | — |
| K27-040/1 PU | 40 | 50 | 43.75 | 5 | 7 | 6.5 | PU9201 | 10014776 | — |
| K27-042 | 42 | 50 | 45 | 5.3 | 7.3 | 7 | NB9001 | 10014778 | — |
| K27-045 | 45 | 55.6 | 48.8 | 5.3 | 7.3 | 7 | NB9001 | 10014783 | — |
| K27-045 PU | 45 | 55.6 | 48.8 | 5.3 | 7.3 | 7 | PU9201 | 10014785 | — |
| K27-045/1 | 45 | 53.6 | 48 | 5.3 | 7.3 | 7 | NB9001 | 10014786 | — |
| K27-045/1 PU | 45 | 53.6 | 48 | 5.3 | 7.3 | 7 | PU9201 | 10014788 | — |
| K27-045/2 | 45 | 53 | 48 | 4.5 | 6.5 | 5.8 | NB9001 | 10014789 | — |
| K27-045/2 PU | 45 | 53 | 48 | 4.5 | 6.5 | 5.8 | PU9201 | 10014791 | — |
| K27-045/3 PU | 45 | 53 | 48.2 | 5.3 | 7.3 | 6.5 | PU9201 | 10014792 | — |
| K27-045/4 PU | 45 | 52.9 | 49 | 5.3 | 6.3 | 6.5 | PU9201 | 10014793 | — |
| K27-047 | 1,875 | 2,24 | 2,01 | 0,206 | 0,285 | 0,276 | NB9001 | 10014794 | — |
| K27-050 | 50 | 60.6 | 53.8 | 5.3 | 7.3 | 7 | NB9001 | 10014795 | — |
| K27-050 PU | 50 | 60.6 | 53.8 | 5.3 | 7.3 | 7 | PU9201 | 10014797 | — |
| K27-050/2 | 50 | 58.6 | 53 | 5.3 | 7.3 | 7 | NB9001 | 10014799 | — |
| K27-050/2 PU | 50 | 58.6 | 53 | 5.3 | 7.3 | 7 | PU9201 | 10014801 | — |
| K27-050/3 | 50 | 58 | 53.2 | 4.8 | 6.8 | 5.8 | NB9001 | 10014802 | — |
| K27-050/3 PU | 50 | 58 | 53.2 | 4.8 | 6.8 | 5.8 | PU9201 | 10014804 | — |
| K27-050/5 PU | 50 | 57.4 | 54 | 5.3 | 7.3 | 6.5 | PU9201 | 10014808 | — |
| K27-055 | 55 | 65.6 | 58.8 | 5.3 | 7.3 | 7 | NB9001 | 10014811 | — |
| K27-055 PU | 55 | 65.6 | 58.8 | 5.3 | 7.3 | 7 | PU9201 | 10014813 | — |
| K27-055/1 PU | 55 | 63 | 58.2 | 5.3 | 7.3 | 7 | PU9201 | 10014815 | — |
| K27-056 | 56 | 64 | 59.2 | 5.3 | 7.3 | 7 | NB9001 | 10014817 | — |
| K27-056 PU | 56 | 64 | 59.2 | 5.3 | 7.3 | 7 | PU9201 | 10014819 | — |
| K27-056/1 PU | 56 | 66 | 59 | 5.6 | 7.6 | 6.8 | PU9201 | 10014821 | — |
| K27-060 | 60 | 70.6 | 63.8 | 5.3 | 7.3 | 7 | NB9001 | 10014823 | — |
| K27-060 PU | 60 | 70.6 | 63.8 | 5.3 | 7.3 | 7 | PU9201 | 10014825 | — |
| K27-060/4 PU | 60 | 68.6 | 63 | 5.3 | 7.3 | 7 | PU9201 | 10014828 | — |
| K27-063 | 63 | 71.6 | 66 | 5.3 | 7.3 | 7 | NB9001 | 10014829 | — |
| K27-063 PU | 63 | 71.6 | 66 | 5.3 | 7.3 | 7 | PU9201 | 10014830 | — |
| K27-063/1 | 63 | 73.6 | 66.8 | 5.3 | 7.3 | 7 | NB9001 | 10014831 | — |
| K27-063/1 PU | 63 | 73.6 | 66.8 | 5.3 | 7.3 | 7 | PU9201 | 10014833 | — |
| K27-065 | 65 | 75.6 | 68.8 | 5.3 | 7.3 | 7 | NB9001 | 10014837 | — |
| K27-065 PU | 65 | 75.6 | 68.8 | 5.3 | 7.3 | 7 | PU9201 | 10014838 | — |
| K27-070 | 70 | 80.6 | 73.8 | 5.3 | 7.3 | 7 | NB9001 | 10014839 | — |
| K27-070 PU | 70 | 80.6 | 73.8 | 5.3 | 7.3 | 7 | PU9201 | 10014841 | — |
| K27-070/3 PU | 70 | 78.6 | 73.1 | 5 | 7 | 7 | PU9201 | 10014844 | — |
| K27-075 | 75 | 87.2 | 81 | 7.1 | 9.1 | 12 | NB9001 | 10014845 | — |
| K27-075 PU | 75 | 87.2 | 81 | 7.1 | 9.1 | 12 | PU9201 | 10014846 | — |
| K27-075/1 PU | 75 | 85 | 78.1 | 5.3 | 7.3 | 7 | PU9201 | 10014847 | — |
| K27-075/2 PU | 75 | 83.6 | 78 | 5.3 | 7.3 | 7 | PU9201 | 10014848 | — |
| K27-080 | 80 | 92 | 86 | 7.1 | 9.1 | 12 | NB9001 | 10014851 | — |
| K27-080 PU | 80 | 92 | 86 | 7.1 | 9.1 | 12 | PU9201 | 10014853 | — |
| K27-080/1 PU | 80 | 90 | 83.5 | 7.3 | 9.3 | 12 | PU9201 | 10014854 | — |
| K27-080/2 PU | 80 | 88 | 83.2 | 5 | 7 | 7 | PU9201 | 10014855 | — |
| K27-085 | 85 | 97.2 | 91 | 7.1 | 9.1 | 12 | NB9001 | 10014856 | — |
| K27-085 PU | 85 | 97.2 | 91 | 7.1 | 9.1 | 12 | PU9201 | 10014857 | — |
| K27-090 | 90 | 102.2 | 96 | 7.1 | 9.1 | 12 | NB9001 | 10014859 | — |
| K27-090 PU | 90 | 102.2 | 96 | 7.1 | 9.1 | 12 | PU9201 | 10014861 | — |
| K27-090/1 | 90 | 100 | 93.2 | 6.3 | 8.3 | 8 | NB9001 | 10014862 | — |
| K27-095 | 95 | 107.2 | 101 | 7.1 | 9.1 | 12 | NB9001 | 10014865 | — |
| K27-095 PU | 95 | 107.2 | 101 | 7.1 | 9.1 | 12 | PU9201 | 10014866 | — |
| K27-100 PU | 100 | 110.2 | 105 | 7 | 9 | 8 | PU9201 | 10014870 | — |
| K27-100/1 PU | 100 | 110.2 | 103.6 | 6 | 8 | 6.8 | PU9201 | 10014871 | — |
| K27-105 PU | 105 | 117.2 | 111 | 7.2 | 9.2 | 12 | PU9201 | 10014874 | — |
| K27-110 | 110 | 125.2 | 117 | 7.8 | 9.8 | 9.5 | NB9001 | 10014875 | — |
| K27-110/1 PU | 110 | 120.2 | 115 | 7 | 9 | 9 | PU9201 | 10014877 | — |
| K27-110/2 PU | 110 | 125.2 | 114 | 8.5 | 10.5 | 9.5 | PU9201 | 10014878 | — |
| K27-110/3 PU | 110 | 122.2 | 116 | 7.2 | 9.2 | 12 | PU9201 | 10014879 | — |
| K27-115 | 115 | 127.2 | 121 | 7.1 | 9.1 | 12 | NB9001 | 10014880 | — |
| K27-115 PU | 115 | 127.2 | 121 | 7.1 | 9.1 | 12 | PU9201 | 10014881 | — |
| K27-120 PU | 120 | 132.2 | 126 | 7.2 | 9.2 | 12 | PU9201 | 10014882 | — |
| K27-125 | 125 | 140 | 129.2 | 7.6 | 9.6 | 9.5 | NB9001 | 10014883 | — |
| K27-125 PU | 125 | 140 | 129.2 | 7.6 | 9.6 | 9.5 | PU9201 | 10014884 | — |
| K27-125/1 PU | 125 | 138 | 132 | 7.3 | 9.3 | 9.5 | PU9201 | 10014885 | — |
| K27-132 PU | 132 | 145 | 139 | 7.3 | 9.3 | 9.5 | PU9201 | 10014888 | — |
| K27-135 | 135 | 147.2 | 141 | 7.1 | 9.1 | 12 | NB9001 | 10014889 | — |
| K27-135 PU | 135 | 147.2 | 141 | 7.1 | 9.1 | 12 | PU9201 | 10014890 | — |
| K27-135/1 PU | 135 | 150 | 141.8 | 7.3 | 9.3 | 12 | PU9201 | 10014891 | — |
| K27-140 PU | 140 | 155 | 147.5 | 10.2 | 12.2 | 16 | PU9201 | 10014893 | — |
| K27-155 | 155 | 167 | 161 | 7.1 | 9.1 | 12 | NB9001 | 10014894 | — |
| K27-155 PU | 155 | 167 | 161 | 7.1 | 9.1 | 12 | PU9201 | 10014895 | — |
| K27-160 | 160 | 172.2 | 166 | 7.1 | 9.1 | 12 | NB9001 | 10014896 | — |
| K27-160 PU | 160 | 172.2 | 166 | 7.1 | 9.1 | 12 | PU9201 | 10014897 | — |
| K27-160/1 | 160 | 175 | 166.8 | 8 | 10 | 11.5 | NB9001 | 10014898 | — |
| K27-160/2 PU | 160 | 175 | 167.6 | 10.2 | 12.2 | 16 | PU9201 | 10014899 | — |
| K27-185 | 185 | 197.2 | 191 | 7.1 | 9.1 | 12 | NB9001 | 10014904 | — |
| K27-185 PU | 185 | 197.2 | 191 | 7.1 | 9.1 | 12 | PU9201 | 10014905 | — |
| K27-200 PU | 200 | 212.2 | 206 | 7.1 | 9.1 | 12 | PU9201 | 10014907 | — |
| K27-215 | 215 | 227 | 221 | 7.1 | 9.1 | 12 | NB9001 | 10014908 | — |
| K27-215 PU | 215 | 227 | 221 | 7.1 | 9.1 | 12 | PU9201 | 10014909 | — |
| K27-220 PU | 220 | 232.2 | 226 | 7.1 | 9.1 | 12 | PU9201 | 10014910 | — |
| K27-240 | 240 | 255 | 247 | 7.1 | 9.1 | 12 | NB9001 | 10014911 | — |
| K27-240 PU | 240 | 255 | 247 | 7.1 | 9.1 | 12 | PU9201 | 10014912 | — |
| K27-280 | 280 | 305 | 292 | 16.5 | 17.8 | 22.5 | NB9001 | 10014914 | — |
| K27-320 | 320 | 350 | 335 | 18 | 20 | 27 | NB9001 | 10014916 | — |
