Toz Keçeleri
K708
Toz Keçesi
- Malzeme
- PTFE NBR
- Kodu
- PT6003 NB7001
- Sıcaklık (max) °C
- -30/+105
- Kayma Hızı (max)- m/s
- 5.0
Avantajları
- Düşük sürtünme
- Statik duruşlarda yapışmama özelliği
- Mil üzerindeki yağ filmini sıyırabilen tasarım
- Geniş ölçü yelpazesi
- Hızlı sistemlerde kullanılabilme
- Basit kanal tasarımı
Uygulama Alanları
- Genel endüstriyel silindirler
- Demir-çelik sektörü
- Enjeksiyon makineleri
- Presler
Teknik Çizim
Ölçü Tablosu
45 ölçü · Kod veya ölçü ile filtreleyin
45 sonuç
| Kod | d (f8) | D (H9) | D1 (H11) | L (+0.2/-0) | amin | r | C | MALZEME | KASTAŞ KOD | |
|---|---|---|---|---|---|---|---|---|---|---|
| K708-010 | 10 | 14.8 | 11.5 | 3.7 | 2 | 0.4 | 2 | PT6003 | 10027931 | — |
| K708-012 | 12 | 18.8 | 13.5 | 5 | 2 | 0.8 | 2.5 | PT6003 | 10027932 | — |
| K708-015 | 15 | 21.8 | 16.5 | 5 | 2 | 0.8 | 2.5 | PT6003 | 10027934 | — |
| K708-016 | 16 | 22.8 | 17.5 | 5 | 2 | 0.8 | 2.5 | PT6003 | 10027936 | — |
| K708-018 | 18 | 22.8 | 19.5 | 3.7 | 2 | 0.4 | 2 | PT6003 | 10027937 | — |
| K708-022 | 22 | 28.8 | 23.5 | 5 | 2 | 0.8 | 2.5 | PT6003 | 10027940 | — |
| K708-022/1 | 22 | 26.8 | 23.5 | 3.7 | 2 | 0.4 | 2 | PT6003 | 10027942 | — |
| K708-025 | 25 | 31.8 | 26.5 | 5 | 2 | 0.8 | 3 | PT6003 | 10027943 | — |
| K708-028 | 28 | 34.8 | 29.5 | 5 | 2 | 0.8 | 3 | PT6003 | 10027944 | — |
| K708-030 | 30 | 36.8 | 31.5 | 5 | 2 | 0.8 | 3 | PT6003 | 10027947 | — |
| K708-032 | 32 | 38.8 | 33.5 | 5 | 2 | 0.8 | 3 | PT6003 | 10027948 | — |
| K708-035 | 35 | 41.8 | 36.5 | 5 | 2 | 0.8 | 3 | PT6003 | 10027949 | — |
| K708-036 | 36 | 42.8 | 37.5 | 5 | 2 | 0.8 | 3 | PT6003 | 10027950 | — |
| K708-040 | 40 | 46.8 | 41.5 | 5 | 2 | 0.8 | 3 | PT6003 | 10027955 | — |
| K708-042 | 42 | 48.8 | 43.5 | 5 | 2 | 0.8 | 3 | PT6003 | 10027958 | — |
| K708-045 | 45 | 51.8 | 46.5 | 5 | 2 | 0.8 | 3 | PT6003 | 10027959 | — |
| K708-050 | 50 | 56.8 | 51.5 | 5 | 2 | 0.8 | 3 | PT6003 | 10027961 | — |
| K708-055 | 55 | 61.8 | 56.5 | 5 | 2 | 0.8 | 3 | PT6003 | 10027964 | — |
| K708-056 | 56 | 62.8 | 57.5 | 5 | 2 | 0.8 | 3 | PT6003 | 10027965 | — |
| K708-060 | 60 | 66.8 | 61.5 | 5 | 2 | 0.8 | 3 | PT6003 | 10027966 | — |
| K708-063 | 63 | 69.8 | 64.5 | 5 | 2 | 0.8 | 3 | PT6003 | 10027968 | — |
| K708-070 | 70 | 78.8 | 71.5 | 6 | 3 | 1 | 4 | PT6003 | 10027969 | — |
| K708-080 | 80 | 88.8 | 81.5 | 6 | 3 | 1 | 4 | PT6003 | 10027972 | — |
| K708-085 | 85 | 93.8 | 86.5 | 6 | 3 | 1 | 4 | PT6003 | 10027974 | — |
| K708-090 | 90 | 98.8 | 91.5 | 6 | 3 | 1 | 4 | PT6003 | 10027975 | — |
| K708-095 | 95 | 103.8 | 96.5 | 6 | 3 | 1 | 4 | PT6003 | 10027976 | — |
| K708-100 | 100 | 108.8 | 101.5 | 6 | 3 | 1 | 4 | PT6003 | 10027977 | — |
| K708-105 | 105 | 113.8 | 106.5 | 6 | 3 | 1 | 4 | PT6003 | 10027979 | — |
| K708-110 | 110 | 118.8 | 111.5 | 6 | 3 | 1 | 4 | PT6003 | 10027980 | — |
| K708-115 | 115 | 123.8 | 116.5 | 6 | 3 | 1 | 4 | PT6003 | 10027981 | — |
| K708-120 | 120 | 128.8 | 121.5 | 6 | 3 | 1 | 4 | PT6003 | 10027982 | — |
| K708-135 | 135 | 143.8 | 136.5 | 6 | 3 | 1 | 4 | PT6003 | 10027986 | — |
| K708-137 | 137 | 145.8 | 138.5 | 6 | 3 | 1 | 4 | PT6003 | 10027987 | — |
| K708-140 | 140 | 148.8 | 141.5 | 6 | 3 | 1 | 4 | PT6003 | 10027988 | — |
| K708-150 | 150 | 158.8 | 151.5 | 6 | 3 | 1 | 4 | PT6003 | 10027989 | — |
| K708-160 | 160 | 168.8 | 161.5 | 6 | 3 | 1 | 4 | PT6003 | 10027991 | — |
| K708-170 | 170 | 178.8 | 171.5 | 6 | 3 | 1 | 4 | PT6003 | 10027994 | — |
| K708-180 | 180 | 188.8 | 181.5 | 6 | 3 | 1 | 4 | PT6003 | 10027996 | — |
| K708-200 | 200 | 208.8 | 201.5 | 6 | 3 | 1 | 4 | PT6003 | 10027999 | — |
| K708-210 | 210 | 218.8 | 211.5 | 6 | 3 | 1 | 4 | PT6003 | 10028000 | — |
| K708-220 | 220 | 228.8 | 221.5 | 6 | 3 | 1 | 4 | PT6003 | 10028002 | — |
| K708-250 | 250 | 258.8 | 251.5 | 6 | 3 | 1 | 4 | PT6003 | 10028003 | — |
| K708-300 | 300 | 312.2 | 302 | 8.4 | 4 | 1.5 | 6 | PT6003 | 10028006 | — |
| K708-360 | 360 | 372.2 | 362 | 8.4 | 4 | 1.5 | 6 | PT6003 | 10028012 | — |
| K708-440 | 440 | 456 | 442 | 11 | 4 | 1.5 | 6 | PT6003 | 10028016 | — |
