Hidrolik Piston Sızdırmazlık Elemanları
K17
Piston Keçesi
- Malzeme
- PTFE NBR
- Kodu
- PT6003 NB7001
- Basınç (max) bar
- 400
- Sıcaklık (max) °C
- -30/+105
- Kayma Hızı (max)- m/s
- 15.0
Avantajları
- Düşük sürtünme, yüzeye yapışmama özelliği
- Mükemmel statik ve dinamik sızdırmazlık
- Uzun hizmet ömrü
- Yüksek akma dayanımı
- Hidrodinamik basıncı engelleyen tasarım
- Yüksek hız ve frekanslarda çalışabilme
- ISO 7425-1 kanala uygun tasarım
Uygulama Alanları
- Vinçler
- Enjeksiyon tezgahları
- Hidrolik pres silindirleri
- Forkliftler
- İş makineleri sektörü
- Servo silindirler
- Hidrolik kırıcılar
- Rüzgar türbinleri
- Otomotiv sektörü
Teknik Çizim
Ölçü Tablosu
224 ölçü · Kod veya ölçü ile filtreleyin
Akma boşluğu (S) tablosu için tıklayınız
224 sonuç
| Kod | D (H8) | d (h9) | L (+0.2/-0) | r1 | C | O-Ring | MALZEME | KASTAŞ KOD | |
|---|---|---|---|---|---|---|---|---|---|
| K17 008-003.1 | 8 | 3.1 | 2.2 | 0.4 | 3 | 2.90x1.78 | PT6003 | 10002539 | — |
| K17 025,4-017,91 | 1 | 0.705 | 0.125 | 0.024 | 0.177 | 17,13X2,62 | PT6003 | 10061118 | — |
| K17 010-005.1 | 10 | 5.1 | 2.2 | 0.4 | 3 | 4.76x1.78 | PT6003 | 10002541 | — |
| K17 031,75-024,26 | 1.25 | 0.955 | 0.125 | 0.024 | 0.177 | 23,47X2,62 | PT6003 | 10061120 | — |
| K17 012-007.1 | 12 | 7.1 | 2.2 | 0.4 | 3 | 6.75x1.78 | PT6003 | 10002542 | — |
| K17 038,1-027,33 | 1.5 | 1.076 | 0.165 | 0.039 | 0.236 | 26,58X3,53 | PT6003 | 10061122 | — |
| K17 014-009.1 | 14 | 9.1 | 2.2 | 0.4 | 3 | 8.73x1.78 | PT6003 | 10002544 | — |
| K17 038,1-030,61 | 1.5 | 1.205 | 0.125 | 0.024 | 0.177 | 29,82X2,62 | PT6003 | 10061121 | — |
| K17 015-007.5 | 15 | 7.5 | 3.2 | 0.6 | 4.5 | 7.60x2.62 | PT6003 | 10002547 | — |
| K17 050,8-039,8 | 2 | 1.567 | 0.165 | 0.039 | 0.236 | 39,69x3,53 | PT6003 | 10002632 | — |
| K17 016-008.5 | 16 | 8.5 | 3.2 | 0.6 | 4.5 | 7.60x2.62 | PT6003 | 10002549 | — |
| K17 050,8-040,03 | 2 | 1.576 | 0.165 | 0.039 | 0.236 | 39,69X3,53 | PT6003 | 10061125 | — |
| K17 018-010.5 | 18 | 10.5 | 3.2 | 0.6 | 4.5 | 9.92x2.62 | PT6003 | 10002556 | — |
| K17 050,8-043,31 | 2 | 1.705 | 0.125 | 0.024 | 0.177 | 42,52X2,62 | PT6003 | 10061124 | — |
| K17 018-013.1 | 18 | 13.1 | 2.2 | 0.6 | 3 | 12.42x1.78 | PT6003 | 10002557 | — |
| K17 057,15-046,38 | 2.25 | 1.826 | 0.165 | 0.039 | 0.236 | 44,45X3,53 | PT6003 | 10061126 | — |
| K17 020-012.5 | 20 | 12.5 | 3.2 | 0.6 | 4.5 | 12.37x2.62 | PT6003 | 10002559 | — |
| K17 057,15-049,66 | 2.25 | 1.955 | 0.125 | 0.024 | 0.177 | 48,90X2,62 | PT6003 | 10061127 | — |
| K17 020-015.1 | 20 | 15.1 | 2.2 | 0.6 | 3 | 14.00x1.78 | PT6003 | 10002562 | — |
| K17 063,5-052,73 | 2.5 | 2.076 | 0.165 | 0.039 | 0.236 | 50,4X3,53 | PT6003 | 10061128 | — |
| K17 022-014.5 | 22 | 14.5 | 3.2 | 0.6 | 4.5 | 13.95x2.62 | PT6003 | 10002565 | — |
| K17 063,5-056 | 2.5 | 2.205 | 0.125 | 0.024 | 0.177 | 55,25X2,62 | PT6003 | 10002671 | — |
| K17 022.15-14.65 | 22.15 | 14.65 | 3.2 | 0.6 | 4.5 | 13.95x2.62 | PT6003 | 10002564 | — |
| K17 024-016.5 | 24 | 16.5 | 3.2 | 0.6 | 4.5 | 15.88x2.62 | PT6003 | 10002570 | — |
| K17 063.5-056 | 2.5 | 2.205 | 0.126 | 0.024 | 0.177 | 55.25x2.62 | PT6003 | 10002671 | — |
| K17 025-014 | 25 | 14 | 4.2 | 1 | 6 | 13.87x3.53 | PT6003 | 10002573 | — |
| K17 069,85-059,08 | 2.75 | 2.326 | 0.165 | 0.039 | 0.236 | 57,15X3,53 | PT6003 | 10061129 | — |
| K17 025-017.5 | 25 | 17.5 | 3.2 | 0.6 | 4.5 | 17.13x2.62 | PT6003 | 10002575 | — |
| K17 076,2-060,55 | 3 | 2.384 | 0.248 | 0.051 | 0.315 | 59,7X5,33 | PT6003 | 10061132 | — |
| K17 025-020.1 | 25 | 20.1 | 2.2 | 0.6 | 3 | 20.35x1.78 | PT6003 | 10002579 | — |
| K17 076,2-065,43 | 3 | 2.576 | 0.165 | 0.039 | 0.236 | 63,5X3,53 | PT6003 | 10061131 | — |
| K17 028-020.5 | 28 | 20.5 | 3.2 | 0.6 | 4.5 | 20.29x2.62 | PT6003 | 10002583 | — |
| K17 076,2-068,71 | 3 | 2.705 | 0.125 | 0.024 | 0.177 | 66,35X2,62 | PT6003 | 10061130 | — |
| K17 030-022.5 | 30 | 22.5 | 3.2 | 0.6 | 4.5 | 21.89x2.62 | PT6003 | 10002587 | — |
| K17 082,5-066,9 | 3.25 | 2.634 | 0.248 | 0.051 | 0.315 | 66,04X5,33 | PT6003 | 10061135 | — |
| K17 032-021 | 32 | 21 | 4.2 | 1 | 6 | 20.22x3.53 | PT6003 | 10002591 | — |
| K17 082,55-071,78 | 3.25 | 2.826 | 0.165 | 0.039 | 0.236 | 71,44X3,53 | PT6003 | 10061134 | — |
| K17 032-024.5 | 32 | 24.5 | 3.2 | 0.6 | 4.5 | 23.81x2.62 | PT6003 | 10002593 | — |
| K17 082,55-075,06 | 3.25 | 2.955 | 0.125 | 0.024 | 0.177 | 72,69X2,62 | PT6003 | 10061133 | — |
| K17 032-027.1 | 32 | 27.1 | 2.2 | 0.6 | 3 | 26.70x1.78 | PT6003 | 10002596 | — |
| K17 082.5-067 | 82.5 | 67 | 6.3 | 1.3 | 8 | 66.04x5.33 | PT6003 | 10002714 | — |
| K17 034-026.5 | 34 | 26.5 | 3.2 | 0.6 | 4.5 | 25.07x2.62 | PT6003 | 10002598 | — |
| K17 088,9-073,25 | 3.5 | 2.884 | 0.248 | 0.051 | 0.315 | 72,40X5,33 | PT6003 | 10061136 | — |
| K17 035-024 | 35 | 24 | 4.2 | 1 | 6 | 23.40x3.53 | PT6003 | 10002599 | — |
| K17 088,9-078,13 | 3.5 | 3.076 | 0.165 | 0.039 | 0.236 | 75,8X5,33 | PT6003 | 10061138 | — |
| K17 035-027.5 | 35 | 27.5 | 3.2 | 0.6 | 4.5 | 26.64x2.62 | PT6003 | 10002600 | — |
| K17 088,9-081,41 | 3.5 | 3.205 | 0.125 | 0.024 | 0.177 | 80,6X2,62 | PT6003 | 10061137 | — |
| K17 035-030.1 | 35 | 30.1 | 2.2 | 0.6 | 3 | 29.87x1.78 | PT6003 | 10002602 | — |
| K17 092,08-076,43 | 3.625 | 3.009 | 0.248 | 0.051 | 0.315 | 75,57X5,33 | PT6003 | 10061139 | — |
| K17 036-028.5 | 36 | 28.5 | 3.2 | 0.6 | 4.5 | 28.25x2.62 | PT6003 | 10002603 | — |
| K17 095,25-079,6 | 3.75 | 3.134 | 0.248 | 0.051 | 0.315 | 78,74X5,33 | PT6003 | 10061140 | — |
| K17 038-030.5 | 38 | 30.5 | 3.2 | 1 | 4.5 | 29.82x2.62 | PT6003 | 10002605 | — |
| K17 101,6-086,1 | 4 | 3.39 | 0.248 | 0.051 | 0.315 | 85,09x5,33 | PT6003 | 10002742 | — |
| K17 040-024.5 | 40 | 24.5 | 6.3 | 1.3 | 8 | 23.17x5.33 | PT6003 | 10002608 | — |
| K17 101.6-086.1 | 4 | 3.39 | 0.248 | 0.051 | 0.315 | 85.09x5.33 | PT6003 | 10002742 | — |
| K17 040-029 | 40 | 29 | 4.2 | 1 | 6 | 28.17x3.53 | PT6003 | 10002610 | — |
| K17 107,95-092,3 | 4.25 | 3.634 | 0.248 | 0.051 | 0.315 | 91,44X5,33 | PT6003 | 10061141 | — |
| K17 040-032.5 | 40 | 32.5 | 3.2 | 0.6 | 4.5 | 31.42x2.62 | PT6003 | 10002617 | — |
| K17 114,3-098,65 | 4.5 | 3.884 | 0.248 | 0.051 | 0.315 | 97,8X5,33 | PT6003 | 10061142 | — |
| K17 042-031 | 42 | 31 | 4.2 | 1 | 6 | 29.75x3.53 | PT6003 | 10002621 | — |
| K17 120,65-105 | 4.75 | 4.134 | 0.248 | 0.051 | 0.315 | 104,14X5,33 | PT6003 | 10061143 | — |
| K17 045-034 | 45 | 34 | 4.2 | 1 | 6 | 32.92x3.53 | PT6003 | 10002625 | — |
| K17 127-111,50 | 5 | 4.39 | 0.248 | 0.051 | 0.315 | 109,54x5,33 | PT6003 | 10002784 | — |
| K17 048-037 | 48 | 37 | 4.2 | 1 | 6 | 36.1x3.53 | PT6003 | 10002630 | — |
| K17 127-116,23 | 5 | 4.576 | 0.165 | 0.039 | 0.236 | 113,90X3,53 | PT6003 | 10061144 | — |
| K17 050-034.5/1 | 50 | 34.5 | 6.3 | 1 | 8 | 34.29x5.33 | PT6003 | 10002635 | — |
| K17 133,35-117,7 | 5.25 | 4.634 | 0.248 | 0.051 | 0.315 | 116,84X5,33 | PT6003 | 10061145 | — |
| K17 050-039 | 50 | 39 | 4.2 | 1 | 6 | 37.69x3.53 | PT6003 | 10002636 | — |
| K17 136,53-115,44 | 5.375 | 4.545 | 0.318 | 0.071 | 0.413 | 113,67X6,99 | PT6003 | 10061146 | — |
| K17 050-042.5 | 50 | 42.5 | 3.2 | 0.6 | 4.5 | 42.52x2.62 | PT6003 | 10002643 | — |
| K17 139,7-118,62 | 5.5 | 4.67 | 0.318 | 0.071 | 0.413 | 116,84X6,99 | PT6003 | 10061147 | — |
| K17 050.8-039.8 | 2 | 1,567 | 0,165 | 0,039 | 0,236 | 39.69x3.53 | PT6003 | 10002632 | — |
| K17 139,7-124,05 | 5.5 | 4.884 | 0.248 | 0.051 | 0.315 | 123,19X5,33 | PT6003 | 10061148 | — |
| K17 052-041 | 52 | 41 | 4.2 | 1 | 6 | 39.69x3.53 | PT6003 | 10002648 | — |
| K17 146,05-130,4 | 5.75 | 5.134 | 0.248 | 0.051 | 0.315 | 129,545,33 | PT6003 | 10061149 | — |
| K17 055-044 | 55 | 44 | 4.2 | 1 | 6 | 42.86x3.53 | PT6003 | 10002653 | — |
| K17 152,4-131,32 | 6 | 5.17 | 0.318 | 0.071 | 0.413 | 129,54X6,99 | PT6003 | 10061150 | — |
| K17 057-046 | 57 | 46 | 4.2 | 1 | 6 | 44.45x3.53 | PT6003 | 10002659 | — |
| K17 152,4-136,75 | 6 | 5.384 | 0.248 | 0.051 | 0.315 | 135,9X5,33 | PT6003 | 10061151 | — |
| K17 058-047 | 58 | 47 | 4.2 | 1 | 6 | 46.04x3.53 | PT6003 | 10002660 | — |
| K17 158,75-137,67 | 6.25 | 5.42 | 0.318 | 0.071 | 0.413 | 135,9X6,99 | PT6003 | 10061152 | — |
| K17 060-044.5 | 60 | 44.5 | 6.3 | 1 | 8 | 43.82x5.33 | PT6003 | 10002662 | — |
| K17 165,1-144,02 | 6.5 | 5.67 | 0.318 | 0.071 | 0.413 | 142,24X6,99 | PT6003 | 10061153 | — |
| K17 060-049 | 60 | 49 | 4.2 | 1 | 6 | 47.63x3.53 | PT6003 | 10002665 | — |
| K17 177,8-156,72 | 7 | 6.17 | 0.318 | 0.071 | 0.413 | 155,60X6,99 | PT6003 | 10061155 | — |
| K17 063-047.5 | 63 | 47.5 | 6.3 | 1.3 | 8 | 47.00x5.33 | PT6003 | 10002673 | — |
| K17 177,8-162,15 | 7 | 6.384 | 0.248 | 0.051 | 0.315 | 161,3X5,33 | PT6003 | 10061154 | — |
| K17 063-052 | 63 | 52 | 4.2 | 1 | 6 | 50.80x3.53 | PT6003 | 10002676 | — |
| K17 190,5-169,42 | 7.5 | 6.67 | 0.318 | 0.071 | 0.413 | 168,3X6,99 | PT6003 | 10061156 | — |
| K17 063-055.5 | 63 | 55.5 | 3.2 | 0.6 | 4.5 | 55.25x2.62 | PT6003 | 10002678 | — |
| K17 196,85-181,2 | 7.75 | 7.134 | 0.248 | 0.051 | 0.315 | 177,17X5,33 | PT6003 | 10061157 | — |
| K17 203,2-182,12 | 8 | 7.17 | 0.318 | 0.071 | 0.413 | 177,17X6,99 | PT6003 | 10061158 | — |
| K17 065-049.5 | 65 | 49.5 | 6.3 | 1.3 | 8 | 47.00x5.33 | PT6003 | 10002681 | — |
| K17 215,9-194,82 | 8.5 | 7.67 | 0.318 | 0.071 | 0.413 | 193,7X6,99 | PT6003 | 10061159 | — |
| K17 065-054 | 65 | 54 | 4.2 | 1 | 6 | 52.39x3.53 | PT6003 | 10002685 | — |
| K17 228,6-207,52 | 9 | 8.17 | 0.318 | 0.071 | 0.413 | 202,57X6,99 | PT6003 | 10061160 | — |
| K17 068-057 | 68 | 57 | 4.2 | 1 | 6 | 55.56x3.53 | PT6003 | 10002690 | — |
| K17 241,3-220,22 | 9.5 | 8.67 | 0.318 | 0.071 | 0.413 | 215,27X6,99 | PT6003 | 10061161 | — |
| K17 070-054.5 | 70 | 54.5 | 6.3 | 1.3 | 8 | 53.34x5.33 | PT6003 | 10002691 | — |
| K17 254-232,92 | 10 | 9.17 | 0.318 | 0.071 | 0.413 | 227,97X6,99 | PT6003 | 10061162 | — |
| K17 070-059 | 70 | 59 | 4.2 | 1 | 6 | 57.15x3.53 | PT6003 | 10002694 | — |
| K17 266,7-245,62 | 10.5 | 9.67 | 0.318 | 0.071 | 0.413 | 240,67X6,99 | PT6003 | 10061163 | — |
| K17 075-059.5 | 75 | 59.5 | 6.3 | 1.3 | 8 | 56.52x5.33 | PT6003 | 10002700 | — |
| K17 279,4-258,32 | 11 | 10.17 | 0.318 | 0.071 | 0.413 | 253,57X6,99 | PT6003 | 10061164 | — |
| K17 075-064 | 75 | 64 | 4.2 | 1 | 6 | 63.09x3.53 | PT6003 | 10002701 | — |
| K17 304,8-283,72 | 12 | 11.17 | 0.318 | 0.071 | 0.413 | 278,77X6,99 | PT6003 | 10061165 | — |
| K17 080-059 | 80 | 59 | 8.1 | 1.8 | 10.5 | 58.00x6.99 | PT6003 | 10002706 | — |
| K17 355,6-331,09 | 14 | 13.035 | 0.318 | 0.071 | 0.472 | 316,87X6,99 | PT6003 | 10061599 | — |
| K17 080-064.5 | 80 | 64.5 | 6.3 | 1.3 | 8 | 62.87x5.33 | PT6003 | 10002708 | — |
| K17 355,6-334,52 | 14 | 13.17 | 0.318 | 0.071 | 0.413 | 329,57X6,99 | PT6003 | 10061166 | — |
| K17 080-069 | 80 | 69 | 4.2 | 1 | 6 | 68.26x3.53 | PT6003 | 10002711 | — |
| K17 406,4-385,32 | 16 | 15.17 | 0.318 | 0.071 | 0.413 | 380,37X6,99 | PT6003 | 10061167 | — |
| K17 457,2-432,69 | 18 | 17.035 | 0.318 | 0.071 | 0.472 | 430,66X6,99 | PT6003 | 10061602 | — |
| K17 085-064 | 85 | 64 | 8.1 | 1.8 | 10.5 | 63.00x6.99 | PT6003 | 10002716 | — |
| K17 085-069.5 | 85 | 69.5 | 6.3 | 1.3 | 8 | 69.22x5.33 | PT6003 | 10002718 | — |
| K17 085-074 | 85 | 74 | 4.2 | 1 | 6 | 73.03x3.53 | PT6003 | 10002720 | — |
| K17 090-069 | 90 | 69 | 8.1 | 1.8 | 10.5 | 68x6.99 | PT6003 | 10002723 | — |
| K17 090-074.5 | 90 | 74.5 | 6.3 | 1.3 | 8 | 72.40x5.33 | PT6003 | 10002725 | — |
| K17 090-079 | 90 | 79 | 4.2 | 1 | 6 | 78.97x3.53 | PT6003 | 10002729 | — |
| K17 095-074 | 95 | 74 | 8.1 | 1.8 | 10.5 | 72.39x6.99 | PT6003 | 10002731 | — |
| K17 095-079.5 | 95 | 79.5 | 6.3 | 1.3 | 8 | 78.74x5.33 | PT6003 | 10002732 | — |
| K17 095-084 | 95 | 84 | 4.2 | 1 | 6 | 82.14x3.53 | PT6003 | 10002734 | — |
| K17 100-079 | 100 | 79 | 8.1 | 1.8 | 10.5 | 77.00x6.99 | PT6003 | 10002736 | — |
| K17 100-084.5 | 100 | 84.5 | 6.3 | 1.3 | 8 | 81.92x5.33 | PT6003 | 10002738 | — |
| K17 100-089 | 100 | 89 | 4.2 | 1 | 6 | 88.50x3.53 | PT6003 | 10002740 | — |
| K17 105-089.5 | 105 | 89.5 | 6.3 | 1.3 | 8 | 88.27x5.33 | PT6003 | 10002747 | — |
| K17 105-094 | 105 | 94 | 4.2 | 1 | 6 | 91.67x3.53 | PT6003 | 10002749 | — |
| K17 108-092.5 | 108 | 92.5 | 6.3 | 1.3 | 8 | 91.44x5.33 | PT6003 | 10002750 | — |
| K17 110-089 | 110 | 89 | 8.1 | 1.8 | 10.5 | 88.00x6.99 | PT6003 | 10002751 | — |
| K17 110-094.5 | 110 | 94.5 | 6.3 | 1.3 | 8 | 91.44x5.33 | PT6003 | 10002753 | — |
| K17 110-099 | 110 | 99 | 4.2 | 1 | 6 | 98.02x3.53 | PT6003 | 10002755 | — |
| K17 115-094 | 115 | 94 | 8.1 | 1.8 | 10.5 | 92.00x7 | PT6003 | 10002759 | — |
| K17 115-099.5 | 115 | 99.5 | 6.3 | 1.3 | 8 | 97.80X5.33 | PT6003 | 10002761 | — |
| K17 120-099 | 120 | 99 | 8.1 | 1.8 | 10.5 | 97.00x7 | PT6003 | 10002766 | — |
| K17 120-104.5 | 120 | 104.5 | 6.3 | 1.3 | 8 | 100.97x5.33 | PT6003 | 10002769 | — |
| K17 120-109 | 120 | 109 | 4.2 | 1 | 6 | 107.54x3.53 | PT6003 | 10002771 | — |
| K17 125-104 | 125 | 104 | 8.1 | 1.8 | 10.5 | 102.00x6.99 | PT6003 | 10002775 | — |
| K17 125-109.5 | 125 | 109.5 | 6.3 | 1.3 | 8 | 107.32x5.33 | PT6003 | 10002777 | — |
| K17 125-114 | 125 | 114 | 4.2 | 1 | 6 | 110.72x3.53 | PT6003 | 10002780 | — |
| K17 127-111.50 | 5 | 4,39 | 0,248 | 0,051 | 0,315 | 109.54x5.33 | PT6003 | 10002784 | — |
| K17 130-109 | 130 | 109 | 8.1 | 1.8 | 10.5 | 107.00x6.99 | PT6003 | 10002786 | — |
| K17 130-114.5 | 130 | 114.5 | 6.3 | 1.3 | 8 | 113.67x5.33 | PT6003 | 10002788 | — |
| K17 135-114 | 135 | 114 | 8.1 | 1.8 | 10.5 | 113.67x6.99 | PT6003 | 10002791 | — |
| K17 140-119 | 140 | 119 | 8.1 | 1.8 | 10.5 | 116.84x6.99 | PT6003 | 10002796 | — |
| K17 140-124.5 | 140 | 124.5 | 6.3 | 1.3 | 8 | 123.19x5.33 | PT6003 | 10002798 | — |
| K17 140-129 | 140 | 129 | 4.2 | 1 | 6 | 126.60x3.53 | PT6003 | 10002800 | — |
| K17 142-121 | 142 | 121 | 8.1 | 1.8 | 10.5 | 116.84x6.99 | PT6003 | 10002802 | — |
| K17 145-124 | 145 | 124 | 8.1 | 1.8 | 10.5 | 123.20x6.99 | PT6003 | 10002803 | — |
| K17 150-129 | 150 | 129 | 8.1 | 1.8 | 10.5 | 126.37x6.99 | PT6003 | 10002807 | — |
| K17 150-134.5 | 150 | 134.5 | 6.3 | 1.3 | 8 | 130.20x5.33 | PT6003 | 10002810 | — |
| K17 155-134 | 155 | 134 | 8.1 | 1.8 | 10.5 | 132.72x6.99 | PT6003 | 10002817 | — |
| K17 160-139 | 160 | 139 | 8.1 | 1.8 | 10.5 | 135.90x6.99 | PT6003 | 10002822 | — |
| K17 160-144.5 | 160 | 144.5 | 6.3 | 1.3 | 8 | 142.24x5.33 | PT6003 | 10002825 | — |
| K17 165-144 | 165 | 144 | 8.1 | 1.8 | 10.5 | 142.24x6.99 | PT6003 | 10002829 | — |
| K17 170-149 | 170 | 149 | 8.1 | 1.8 | 10.5 | 145.42X6.99 | PT6003 | 10002834 | — |
| K17 175-154 | 175 | 154 | 8.1 | 1.8 | 10.5 | 151.77x6.99 | PT6003 | 10002838 | — |
| K17 180-159 | 180 | 159 | 8.1 | 1.8 | 10.5 | 158.12x6.99 | PT6003 | 10002841 | — |
| K17 185-164 | 185 | 164 | 8.1 | 1.8 | 10.5 | 161.90X6. 99 | PT6003 | 10002846 | — |
| K17 185-169.5 | 185 | 169.5 | 6.3 | 1.3 | 8 | 164.47X5.33 | PT6003 | 10002847 | — |
| K17 190-169 | 190 | 169 | 8.1 | 1.8 | 10.5 | 168.30x6.99 | PT6003 | 10002849 | — |
| K17 195-174 | 195 | 174 | 8.1 | 1.8 | 10.5 | 170.82x6.99 | PT6003 | 10002857 | — |
| K17 195-179.5 | 195 | 179.5 | 6.3 | 1.3 | 8 | 177.17x5.33 | PT6003 | 10002858 | — |
| K17 200-179 | 200 | 179 | 8.1 | 1.8 | 10.5 | 177.17x6.99 | PT6003 | 10002859 | — |
| K17 200-184.5 | 200 | 184.5 | 6.3 | 1.3 | 8 | 183.52x5.33 | PT6003 | 10002863 | — |
| K17 205-184 | 205 | 184 | 8.1 | 1.8 | 10.5 | 183.52X6.99 | PT6003 | 10002871 | — |
| K17 210-189 | 210 | 189 | 8.1 | 1.8 | 10.5 | 187.3X6.99 | PT6003 | 10002872 | — |
| K17 215-194 | 215 | 194 | 8.1 | 1.8 | 10.5 | 189.87x6.99 | PT6003 | 10002875 | — |
| K17 220-199 | 220 | 199 | 8.1 | 1.8 | 10.5 | 196.22x6.99 | PT6003 | 10002877 | — |
| K17 225-204 | 225 | 204 | 8.1 | 1.8 | 10.5 | 202.57x6.99 | PT6003 | 10002881 | — |
| K17 230-209 | 230 | 209 | 8.1 | 1.8 | 10.5 | 202.57x6.99 | PT6003 | 10002887 | — |
| K17 240-219 | 240 | 219 | 8.1 | 1.8 | 10.5 | 215.27X6.99 | PT6003 | 10002891 | — |
| K17 245-224 | 245 | 224 | 8.1 | 1.8 | 10.5 | 221.62X6.99 | PT6003 | 10002894 | — |
| K17 250-229 | 250 | 229 | 8.1 | 1.8 | 10.5 | 227. 97X6. 99 | PT6003 | 10002895 | — |
| K17 254-233 | 254 | 233 | 8.1 | 1.8 | 10.5 | 227.97X6.99 | PT6003 | 10002900 | — |
| K17 255-234 | 255 | 234 | 8.1 | 1.8 | 10.5 | 227. 97X6. 99 | PT6003 | 10002901 | — |
| K17 260-239 | 260 | 239 | 8.1 | 1.8 | 10.5 | 234.32X6.99 | PT6003 | 10002904 | — |
| K17 265-244 | 265 | 244 | 8.1 | 1.8 | 10.5 | 240.67X6.99 | PT6003 | 10002906 | — |
| K17 270-249 | 270 | 249 | 8.1 | 1.8 | 10.5 | 247.00x6.99 | PT6003 | 10002907 | — |
| K17 275-254 | 275 | 254 | 8.1 | 1.8 | 10.5 | 247.00x6.99 | PT6003 | 10002910 | — |
| K17 280-259 | 280 | 259 | 8.1 | 1.8 | 10.5 | 253.57x6.99 | PT6003 | 10002913 | — |
| K17 290-269 | 290 | 269 | 8.1 | 1.8 | 10.5 | 266.07x6.99 | PT6003 | 10002919 | — |
| K17 300-275.5 | 300 | 275.5 | 8.1 | 1.8 | 12 | 272.40x6.99 | PT6003 | 10002922 | — |
| K17 300-279 | 300 | 279 | 8.1 | 1.8 | 10.5 | 278.77x6.99 | PT6003 | 10002923 | — |
| K17 305-284 | 305 | 284 | 8.1 | 1.8 | 10.5 | 278.77x6.99 | PT6003 | 10002927 | — |
| K17 310-289 | 310 | 289 | 8.1 | 1.8 | 10.5 | 285.1x6.99 | PT6003 | 10002930 | — |
| K17 315-294 | 315 | 294 | 8.1 | 1.8 | 10.5 | 291.47x6.99 | PT6003 | 10002935 | — |
| K17 320-295.5 | 320 | 295.5 | 8.1 | 1.8 | 12 | 291.47x6.99 | PT6003 | 10002936 | — |
| K17 320-299 | 320 | 299 | 8.1 | 1.8 | 10.5 | 297.88x6.99 | PT6003 | 10002937 | — |
| K17 325-300.5 | 325 | 300.5 | 8.1 | 1.8 | 12 | 297.88x6.99 | PT6003 | 10002939 | — |
| K17 325-304 | 325 | 304 | 8.1 | 1.8 | 10.5 | 297.88x6.99 | PT6003 | 10002940 | — |
| K17 330-305.5 | 330 | 305.5 | 8.1 | 1.8 | 12 | 304.17x6.99 | PT6003 | 10002942 | — |
| K17 340-315.5 | 340 | 315.5 | 8.1 | 1.8 | 12 | 310.50x6.99 | PT6003 | 10002947 | — |
| K17 350-325.5 | 350 | 325.5 | 8.1 | 1.8 | 12 | 323.20x6.99 | PT6003 | 10002951 | — |
| K17 360-335.5 | 360 | 335.5 | 8.1 | 1.8 | 12 | 329.57x6.99 | PT6003 | 10002959 | — |
| K17 365-340.5 | 365 | 340.5 | 8.1 | 1.8 | 12 | 335.90x6.99 | PT6003 | 10002961 | — |
| K17 370-345.5 | 370 | 345.5 | 8.1 | 1.8 | 12 | 342.27x6.99 | PT6003 | 10002962 | — |
| K17 375-350.5 | 375 | 350.5 | 8.1 | 1.8 | 12 | 342.27X6.99 | PT6003 | 10002963 | — |
| K17 380-355.5 | 380 | 355.5 | 8.1 | 1.8 | 12 | 354.90x6.99 | PT6003 | 10002964 | — |
| K17 390-365.5 | 390 | 365.5 | 8.1 | 1.8 | 12 | 354.90x6.99 | PT6003 | 10002967 | — |
| K17 400-375.5 | 400 | 375.5 | 8.1 | 1.8 | 12 | 367.67x6.99 | PT6003 | 10002970 | — |
| K17 415-390.5 | 415 | 390.5 | 8.1 | 1.8 | 12 | 380.37x6.99 | PT6003 | 10002984 | — |
| K17 420-395.5 | 420 | 395.5 | 8.1 | 1.8 | 12 | 393.07x6.99 | PT6003 | 10002985 | — |
| K17 430-405.5 | 430 | 405.5 | 8.1 | 1.8 | 12 | 393.07x6.99 | PT6003 | 10002987 | — |
| K17 440-415.5 | 440 | 415.5 | 8.1 | 1.8 | 12 | 405.26x6.99 | PT6003 | 10002990 | — |
| K17 450-425.5 | 450 | 425.5 | 8.1 | 1.8 | 12 | 417.96x6.99 | PT6003 | 10002992 | — |
| K17 460-435.5 | 460 | 435.5 | 8.1 | 1.8 | 12 | 430.66x6.99 | PT6003 | 10002997 | — |
| K17 470-445.5 | 470 | 445.5 | 8.1 | 1.8 | 12 | 443.36x6.99 | PT6003 | 10003000 | — |
| K17 475-450.5 | 475 | 450.5 | 8.1 | 1.8 | 12 | 443.36x6.99 | PT6003 | 10003001 | — |
| K17 480-455.5 | 480 | 455.5 | 8.1 | 1.8 | 12 | 443.36x6.99 | PT6003 | 10003002 | — |
| K17 485-460.5 | 485 | 460.5 | 8.1 | 1.8 | 12 | 456.06x6.99 | PT6003 | 10003004 | — |
| K17 495-470.5 | 495 | 470.5 | 8.1 | 1.8 | 12 | 468.76x6.99 | PT6003 | 10003006 | — |
| K17 500-475.5 | 500 | 475.5 | 8.1 | 1.8 | 12 | 468.76x6.99 | PT6003 | 10003007 | — |
| K17 520-495.5 | 520 | 495.5 | 8.1 | 1.8 | 12 | 494.16x6.99 | PT6003 | 10003009 | — |
| K17 530-505.5 | 530 | 505.5 | 8.1 | 1.8 | 12 | 494.16x6.99 | PT6003 | 10003011 | — |
| K17 540-515.5 | 540 | 515.5 | 8.1 | 1.8 | 12 | 506.86x6.99 | PT6003 | 10003012 | — |
| K17 550-525.5 | 550 | 525.5 | 8.1 | 1.8 | 12 | 506.86x6.99 | PT6003 | 10003014 | — |
| K17 560-535.5 | 560 | 535.5 | 8.1 | 1.8 | 12 | 532.26x6.99 | PT6003 | 10003015 | — |
| K17 565-540.5 | 565 | 540.5 | 8.1 | 1.8 | 12 | 532.26x6.99 | PT6003 | 10003016 | — |
| K17 580-555.5 | 580 | 555.5 | 8.1 | 1.8 | 12 | 557.66x6.99 | PT6003 | 10003018 | — |
| K17 600-575.5 | 600 | 575.5 | 8.1 | 1.8 | 12 | 557.66x6.99 | PT6003 | 10003019 | — |
| K17 610-585.5 | 610 | 585.5 | 8.1 | 1.8 | 12 | 582.68x6.99 | PT6003 | 10003020 | — |
| K17 640-615.5 | 640 | 615.5 | 8.1 | 1.8 | 12 | 608.08x6.99 | PT6003 | 10003025 | — |
| K17 660-635.5 | 660 | 635.5 | 8.1 | 1.8 | 12 | 622.00x6.99 | PT6003 | 10003027 | — |
| K17 063,5-056 | 2.5 | 2.205 | 0.024 | 0.177 | 55,25X2,62 | PT6003 | 10002671 | — |
