K17X

Hidrolik Piston Sızdırmazlık Elemanları

K17X

Yüksek Performans Piston Keçesi

Malzeme
NBR PTFE
Kodu
PT6003 NB7001
Basınç (max) bar
400
Sıcaklık (max) °C
-30/+105
Kayma Hızı (max)- m/s
15.0
WhatsApp Broşür (PDF)

Avantajları

  • Blow-by etkisini önleyen tasarım
  • Düşük sürtünme, yüzeye yapışmama özelliği
  • Mükemmel statik ve dinamik sızdırmazlık
  • Uzun hizmet ömrü
  • Yüksek akma dayanımı
  • Hidrodinamik basıncı engelleyen tasarım
  • Yüksek hız ve frekanslarda çalışabilme
  • ISO 7425-1 kanala uygun tasarım

Uygulama Alanları

  • Vinçler
  • Enjeksiyon tezgahları
  • Hidrolik pres silindirleri
  • Forkliftler
  • İş makineleri sektörü
  • Servo silindirler
  • Hidrolik kırıcılar
  • Rüzgar türbinleri
  • Otomotiv endüstrisi

Teknik Çizim

K17X teknik çizim

Ölçü Tablosu

74 ölçü · Kod veya ölçü ile filtreleyin

Akma boşluğu (S) tablosu için tıklayınız
Filtrele

74 sonuç

KodD (H8)d (h9)L (+0.2/-0)r1CO-RingMALZEMEKASTAŞ KODPDF
K17X 025-017.52517.53.20.64.517.13x2.62PT600310003040 indir
K17X 127-111.5054,390,2480,0510,315109.54x5.33PT600310003072 indir
K17X 028-020.52820.53.20.64.520.29x2.62PT600310003041 indir
K17X 030-022.53022.53.20.64.522.22x2.62PT600310003042 indir
K17X 032-024.53224.53.20.64.523.81x2.62PT600310003043 indir
K17X 034-026.53426.53.20.64.525.07x2.62PT600310003044 indir
K17X 035-027.53527.53.20.64.526.64x2.62PT600310003045 indir
K17X 040-02940294.21628.17x3.53PT600310003046 indir
K17X 045-03445344.21632.92x3.53PT600310003047 indir
K17X 048-03748374.21636.10x3.53PT600310003048 indir
K17X 050-03950394.21637.69x3.53PT600310003050 indir
K17X 055-04455444.21642.86x3.53PT600310003052 indir
K17X 060-04960494.21647.63x3.53PT600310003053 indir
K17X 063-05263524.21650.80x3.53PT600310003054 indir
K17X 065-05465544.21653.57x3.53PT600310003055 indir
K17X 070-054.57054.56.31.3853.34x5.33PT600310003056 indir
K17X 070-05970594.21658.74x3.53PT600310003057 indir
K17X 075-06475644.21663.09x3.53PT600310003058 indir
K17X 080-064.58064.56.31.3862.87x5.33PT600310003059 indir
K17X 085-069.58569.56.31.3869.22x5.33PT600310003060 indir
K17X 090-074.59074.56.31.3872.40x5.33PT600310003061 indir
K17X 095-079.59579.56.31.3878.74x5.33PT600310003062 indir
K17X 100-084.510084.56.31.3881.92x5.33PT600310003063 indir
K17X 105-089.510589.56.31.3888.27x5.33PT600310003065 indir
K17X 110-094.511094.56.31.3891.44x5.33PT600310003066 indir
K17X 115-099.511599.56.31.3897.80x5.33PT600310003068 indir
K17X 120-104.5120104.56.31.38104.14x5.33PT600310003069 indir
K17X 125-109.5125109.56.31.38107.32x5.33PT600310003071 indir
K17X 130-114.5130114.56.31.38113.67x5.33PT600310003073 indir
K17X 140-124.5140124.56.31.38123.80x5.33PT600310003074 indir
K17X 150-1291501298.11.810.5126.37x6.99PT600310003075 indir
K17X 155-1341551348.11.810.5132.72x6.99PT600310003076 indir
K17X 160-1391601398.11.810.5135.90x6.99PT600310003077 indir
K17X 165-1441651448.11.810.5142.24x6.99PT600310003078 indir
K17X 170-1491701498.11.810.5148.60X6.99PT600310003079 indir
K17X 175-1541751548.11.810.5151.77x6.99PT600310003080 indir
K17X 180-1591801598.11.810.5155.60x6.99PT600310003081 indir
K17X 185-1641851648.11.810.5161.90x6.99PT600310003082 indir
K17X 190-1691901698.11.810.5168.30x6.99PT600310003083 indir
K17X 195-1741951748.11.810.5170.82x6.99PT600310003084 indir
K17X 200-1792001798.11.810.5177.17x6.99PT600310003085 indir
K17X 205-1842051848.11.810.5183.52X6.99PT600310003086 indir
K17X 210-1892101898.11.810.5187.3X6.99PT600310003087 indir
K17X 215-1942151948.11.810.5189.87x6.99PT600310003088 indir
K17X 220-1992201998.11.810.5196.22x6.99PT600310003089 indir
K17X 225-2042252048.11.810.5199.80x6.99PT600310003090 indir
K17X 230-2092302098.11.810.5202.57x6.99PT600310003091 indir
K17X 240-2192402198.11.810.5215.27X6.99PT600310003092 indir
K17X 245-2242452248.11.810.5221.62X6.99PT600310003093 indir
K17X 250-2292502298.11.810.5227.97x6.99PT600310003094 indir
K17X 255-2342552348.11.810.5227.97X6.99PT600310003095 indir
K17X 260-2392602398.11.810.5234.32x6.99PT600310003096 indir
K17X 265-2442652448.11.810.5240.67x6.99PT600310003097 indir
K17X 270-2492702498.11.810.5247.00x6.99PT600310003098 indir
K17X 275-2542752548.11.810.5253.57x6.99PT600310003099 indir
K17X 280-2592802598.11.810.5253.57x6.99PT600310003100 indir
K17X 290-2692902698.11.810.5266.07x6.99PT600310003101 indir
K17X 300-2793002798.11.810.5272.40x6.99PT600310003102 indir
K17X 305-2843052848.11.810.5278.77x6.99PT600310003103 indir
K17X 310-2893102898.11.810.5285.1x6.99PT600310003104 indir
K17X 315-2943152948.11.810.5291.47x6.99PT600310003105 indir
K17X 320-2993202998.11.810.5291.47x6.99PT600310003106 indir
K17X 325-3043253048.11.810.5297.88x6.99PT600310003107 indir
K17X 330-305.5330305.58.11.812304.17x6.99PT600310003108 indir
K17X 340-315.5340315.58.11.812310.50x6.99PT600310003109 indir
K17X 350-325.5350325.58.11.812323.20x6.99PT600310003110 indir
K17X 360-335.5360335.58.11.812329.57x6.99PT600310003111 indir
K17X 365-340.5365340.58.11.812335.90x6.99PT600310003112 indir
K17X 370-345.5370345.58.11.812342.27x6.99PT600310003113 indir
K17X 375-350.5375350.58.11.812342.27X6.99PT600310003114 indir
K17X 380-355.5380355.58.11.812354.90x6.99PT600310003115 indir
K17X 390-365.5390365.58.11.812354.90x6.99PT600310003116 indir
K17X 400-375.5400375.58.11.812367.67x6.99PT600310003117 indir
K17X 420-395.5420395.58.11.812393.07x6.99PT600310003118 indir
