Hidrolik Piston Sızdırmazlık Elemanları
K503
Kompakt Piston Keçesi
- Malzeme
- NBR TPE POM
- Kodu
- NB8001 TP7301 PM9901
- Basınç (max) bar
- 500
- Sıcaklık (max) °C
- -30/+100
- Kayma Hızı (max)- m/s
- 0.5
Avantajları
- Üstün sızdırmazlık özelliği
- Kompakt dizaynı sayesinde ilave yataklama elemanına ihtiyaç duymaması
- Tek parçalı pistonda basit kanal tasarımı
- Kolay montaj yapılabilmesi
Uygulama Alanları
- Standart endüstriyel tip silindirler
Teknik Çizim
Ölçü Tablosu
60 ölçü · Kod veya ölçü ile filtreleyin
60 sonuç
| Kod | D (H8) | d (h9) | L (+0.2/-0) | ds (h8) | d1 (±0.1) | L1 (+0.2/-0) | C | MALZEME | KASTAŞ KOD | |
|---|---|---|---|---|---|---|---|---|---|---|
| K503 028.57-019.05 | 28.57 | 19.05 | 11.1 | 23.8 | 27.05 | 6.35 | 2.5 | NB8001 | 10021509 | — |
| K503 031.75-022.22 | 31.75 | 22.22 | 11.1 | 26.97 | 30.22 | 6.35 | 2.5 | NB8001 | 10021510 | — |
| K503 034.92-025.4 | 34.92 | 25.4 | 11.1 | 30.15 | 33.4 | 6.35 | 2.5 | NB8001 | 10021511 | — |
| K503 038.1-028.57 | 38.1 | 28.57 | 11.1 | 33.55 | 36.57 | 6.35 | 2.5 | NB8001 | 10021512 | — |
| K503 038.1-028.57/1 | 38.1 | 28.57 | 11.1 | 33.32 | 36.57 | 9.52 | 2.5 | NB8001 | 10021513 | — |
| K503 041.27-031.75 | 41.27 | 31.75 | 11.1 | 36.47 | 39.75 | 9.52 | 2.5 | NB8001 | 10021514 | — |
| K503 044.45-034.92 | 44.45 | 34.92 | 11.1 | 39.65 | 42.92 | 9.52 | 2.5 | NB8001 | 10021515 | — |
| K503 047.62-038.1 | 47.62 | 38.1 | 11.1 | 42.82 | 46.1 | 9.52 | 2.5 | NB8001 | 10021516 | — |
| K503 050.8-038.1 | 50.8 | 38.1 | 14.52 | 46.25 | 49.28 | 6.35 | 3.5 | NB8001 | 10021517 | — |
| K503 050.8-038.1/1 | 50.8 | 38.1 | 14.52 | 46 | 49.28 | 9.52 | 3.5 | NB8001 | 10021518 | — |
| K503 057.15-044.45 | 57.15 | 44.45 | 14.52 | 52.35 | 55.63 | 9.52 | 3.5 | NB8001 | 10021519 | — |
| K503 063.5-050.8 | 63.5 | 50.8 | 14.52 | 58.95 | 61.98 | 6.35 | 3.5 | NB8001 | 10021520 | — |
| K503 063.5-050.8/1 | 63.5 | 50.8 | 14.52 | 58.7 | 61.98 | 9.52 | 3.5 | NB8001 | 10021521 | — |
| K503 069.85-057.15 | 69.75 | 57.15 | 14.52 | 65 | 68.33 | 9.52 | 3.5 | NB8001 | 10021522 | — |
| K503 076.1-063.5 | 76.2 | 63.5 | 14.52 | 70.46 | 74.68 | 6.35 | 3.5 | NB8001 | 10021523 | — |
| K503 076.1-063.5/1 | 76.2 | 63.5 | 14.52 | 71.35 | 74.68 | 9.52 | 3.5 | NB8001 | 10021524 | — |
| K503 082.55-069.85 | 82.55 | 69.85 | 14.52 | 77.7 | 81.03 | 9.52 | 3.5 | NB8001 | 10021525 | — |
| K503 088.9-076.2 | 88.9 | 76.2 | 14.52 | 83.16 | 87.38 | 6.35 | 3.5 | NB8001 | 10021526 | — |
| K503 088.9-076.2/1 | 88.9 | 76.2 | 14.52 | 84.05 | 87.38 | 9.52 | 3.5 | NB8001 | 10021527 | — |
| K503 095.25-082.55 | 95.25 | 82.55 | 14.52 | 88.67 | 93.22 | 12.7 | 3.5 | NB8001 | 10021528 | — |
| K503 101.6-082.55 | 101.6 | 82.55 | 19.43 | 95.83 | 99.57 | 6.35 | 5 | NB8001 | 10021529 | — |
| K503 101.6-082.55/1 | 101.6 | 82.55 | 19.43 | 95.07 | 99.57 | 12.7 | 5 | NB8001 | 10021530 | — |
| K503 107.95-088.9 | 107.95 | 88.9 | 19.43 | 101.42 | 105.92 | 12.7 | 5 | NB8001 | 10021531 | — |
| K503 114.3-095.25 | 114.3 | 95.25 | 19.43 | 107.72 | 112.27 | 12.7 | 5 | NB8001 | 10021532 | — |
| K503 120.65-101.6 | 120.65 | 101.6 | 19.43 | 114.07 | 118.68 | 12.7 | 5 | NB8001 | 10021533 | — |
| K503 127-107.95 | 127 | 107.95 | 19.43 | 120.42 | 124.97 | 12.7 | 5 | NB8001 | 10021534 | — |
| K503 139.7-120.65 | 139.7 | 120.65 | 19.43 | 133.12 | 137.67 | 12.7 | 5 | NB8001 | 10021535 | — |
| K503 152.4-133.35 | 152.4 | 133.35 | 19.43 | 145.82 | 150.37 | 12.7 | 5 | NB8001 | 10021536 | — |
| K503 177.8-158.75 | 177.8 | 158.75 | 19.43 | 171.22 | 175.77 | 12.7 | 5 | NB8001 | 10021537 | — |
| K503 203.2-184.15 | 203.2 | 184.15 | 19.43 | 196.62 | 201.17 | 12.7 | 5 | NB8001 | 10021538 | — |
| K503 028,57-019,05 | 1.125 | 0.75 | 0.437 | 0.937 | 1.065 | 0.25 | 0.098 | NB8001 | 10021509 | — |
| K503 088,9-076,2 | 3.5 | 3 | 0.572 | 3.274 | 3.44 | 0.25 | 0.138 | NB8001 | 10021526 | — |
| K503 082,55-069,85 | 3.25 | 2.75 | 0.572 | 3.059 | 3.19 | 0.375 | 0.138 | NB8001 | 10021525 | — |
| K503 076,1-063,5/1 | 3 | 2.5 | 0.572 | 2.809 | 2.94 | 0.375 | 0.138 | NB8001 | 10021524 | — |
| K503 076,1-063,5 | 3 | 2.5 | 0.572 | 2.774 | 2.94 | 0.25 | 0.138 | NB8001 | 10021523 | — |
| K503 069,85-057,15 | 2.746 | 2.25 | 0.572 | 2.559 | 2.69 | 0.375 | 0.138 | NB8001 | 10021522 | — |
| K503 063,5-050,8/1 | 2.5 | 2 | 0.572 | 2.311 | 2.44 | 0.375 | 0.138 | NB8001 | 10021521 | — |
| K503 063,5-050,8 | 2.5 | 2 | 0.572 | 2.321 | 2.44 | 0.25 | 0.138 | NB8001 | 10021520 | — |
| K503 057,15-044,45 | 2.25 | 1.75 | 0.572 | 2.061 | 2.19 | 0.375 | 0.138 | NB8001 | 10021519 | — |
| K503 050,8-038,1 | 2 | 1.5 | 0.572 | 1.821 | 1.94 | 0.25 | 0.138 | NB8001 | 10021517 | — |
| K503 047,62-038,1 | 1.875 | 1.5 | 0.437 | 1.686 | 1.815 | 0.375 | 0.098 | NB8001 | 10021516 | — |
| K503 044,45-034,92 | 1.75 | 1.375 | 0.437 | 1.561 | 1.69 | 0.375 | 0.098 | NB8001 | 10021515 | — |
| K503 041,27-031,75 | 1.625 | 1.25 | 0.437 | 1.436 | 1.565 | 0.375 | 0.098 | NB8001 | 10021514 | — |
| K503 038,1-028,57/1 | 1.5 | 1.125 | 0.437 | 1.312 | 1.44 | 0.375 | 0.098 | NB8001 | 10021513 | — |
| K503 038,1-028,57 | 1.5 | 1.125 | 0.437 | 1.321 | 1.44 | 0.25 | 0.098 | NB8001 | 10021512 | — |
| K503 034,92-025,4 | 1.375 | 1 | 0.437 | 1.187 | 1.315 | 0.25 | 0.098 | NB8001 | 10021511 | — |
| K503 031,75-022,22 | 1.25 | 0.875 | 0.437 | 1.062 | 1.19 | 0.25 | 0.098 | NB8001 | 10021510 | — |
| K503 050,8-038,1/1 | 2 | 1.5 | 0.572 | 1.811 | 1.94 | 0.375 | 0.138 | NB8001 | 10021518 | — |
| K503 203,2-184,15 | 8 | 7.25 | 0.765 | 7.741 | 7.92 | 0.5 | 0.197 | NB8001 | 10021538 | — |
| K503 177,8-158,75 | 7 | 6.25 | 0.765 | 6.741 | 6.92 | 0.5 | 0.197 | NB8001 | 10021537 | — |
| K503 152,4-133,35 | 6 | 5.25 | 0.765 | 5.741 | 5.92 | 0.5 | 0.197 | NB8001 | 10021536 | — |
| K503 139,7-120,65 | 5.5 | 4.75 | 0.765 | 5.241 | 5.42 | 0.5 | 0.197 | NB8001 | 10021535 | — |
| K503 127-107,95 | 5 | 4.25 | 0.765 | 4.741 | 4.92 | 0.5 | 0.197 | NB8001 | 10021534 | — |
| K503 120,65-101,6 | 4.75 | 4 | 0.765 | 4.491 | 4.672 | 0.5 | 0.197 | NB8001 | 10021533 | — |
| K503 114,3-095,25 | 4.5 | 3.75 | 0.765 | 4.241 | 4.42 | 0.5 | 0.197 | NB8001 | 10021532 | — |
| K503 107,95-088,9 | 4.25 | 3.5 | 0.765 | 3.993 | 4.17 | 0.5 | 0.197 | NB8001 | 10021531 | — |
| K503 101,6-082,55/1 | 4 | 3.25 | 0.765 | 3.743 | 3.92 | 0.5 | 0.197 | NB8001 | 10021530 | — |
| K503 101,6-082,55 | 4 | 3.25 | 0.765 | 3.773 | 3.92 | 0.25 | 0.197 | NB8001 | 10021529 | — |
| K503 095,25-082,55 | 3.75 | 3.25 | 0.572 | 3.491 | 3.67 | 0.5 | 0.138 | NB8001 | 10021528 | — |
| K503 088,9-076,2/1 | 3.5 | 3 | 0.572 | 3.309 | 3.44 | 0.375 | 0.138 | NB8001 | 10021527 | — |
