Hidrolik Piston Sızdırmazlık Elemanları
K26
Piston Keçesi
- Malzeme
- NBR SAC YAY
- Kodu
- NB9001 FE9901 CN9901
- Basınç (max) bar
- 60
- Sıcaklık (max) °C
- -30/+105
- Kayma Hızı (max)- m/s
- 0.5
Avantajları
- Uzun hizmet ömrü
- Piston başına gerek duymayan rijit gövde yapısı
- Pnömatik sistemlerde de kullanılabilme
Uygulama Alanları
- Hafif hizmet silindirleri
- Tarım sektörü
- Düşük basınçlı endüstriyel silindirler
Teknik Çizim
Ölçü Tablosu
48 ölçü · Kod veya ölçü ile filtreleyin
48 sonuç
| Kod | D (H11) | d (f9) | H | b | k | C | MALZEME | KASTAŞ KOD | |
|---|---|---|---|---|---|---|---|---|---|
| K26-025 | 25 | 8 | 22 | 3.5 | 3 | 5 | NB9001 | 10014496 | — |
| K26-026 | 26 | 8 | 22 | 3.5 | 3 | 5 | NB9001 | 10014499 | — |
| K26-030 | 30 | 8 | 22 | 3.5 | 3 | 5 | NB9001 | 10014501 | — |
| K26-032 | 32 | 8 | 25 | 3.5 | 3 | 5 | NB9001 | 10014504 | — |
| K26-035 | 35 | 8 | 26 | 3.5 | 3 | 5 | NB9001 | 10014506 | — |
| K26-035/1 | 35 | 8 | 18 | 2.5 | 2 | 5 | NB9001 | 10014509 | — |
| K26-038 | 38 | 8 | 25 | 3.5 | 3 | 5 | NB9001 | 10014512 | — |
| K26-040 | 40 | 10 | 25 | 3.5 | 3 | 5 | NB9001 | 10014516 | — |
| K26-040/1 | 40 | 14 | 23 | 5.9 | 5 | 5 | NB9001 | 10014518 | — |
| K26-040/2 | 40 | 10 | 25 | 3.5 | 3 | 5 | NB9001 | 10014520 | — |
| K26-045 | 45 | 10 | 25 | 4.5 | 4 | 5 | NB9001 | 10014522 | — |
| K26-046 | 46 | 10 | 25 | 4.5 | 4 | 5 | NB9001 | 10014526 | — |
| K26-050 | 50 | 10 | 25 | 4.5 | 4 | 5 | NB9001 | 10014527 | — |
| K26-050/1 | 50 | 16 | 23 | 5.9 | 5 | 5 | NB9001 | 10014531 | — |
| K26-055 | 55 | 10 | 25 | 4.5 | 4 | 5 | NB9001 | 10014536 | — |
| K26-060 | 60 | 12 | 26 | 4.5 | 4 | 5 | NB9001 | 10014541 | — |
| K26-060/1 | 60 | 21 | 26 | 4.5 | 4 | 5 | NB9001 | 10014545 | — |
| K26-060/2 | 60 | 12 | 27 | 4.5 | 4 | 5 | NB9001 | 10014547 | — |
| K26-062 | 62 | 41 | 30 | 5.9 | 5 | 5 | NB9001 | 10014551 | — |
| K26-063 | 63 | 12 | 25 | 4.5 | 4 | 5 | NB9001 | 10014553 | — |
| K26-065 | 65 | 12 | 25 | 4.5 | 4 | 5 | NB9001 | 10014556 | — |
| K26-070 | 70 | 12 | 30 | 5.9 | 5 | 5 | NB9001 | 10014561 | — |
| K26-075 | 75 | 12 | 30 | 5.9 | 5 | 5 | NB9001 | 10014565 | — |
| K26-080 | 80 | 12 | 30 | 5.9 | 5 | 5 | NB9001 | 10014568 | — |
| K26-085 | 85 | 12 | 35 | 7.1 | 6 | 15.5 | NB9001 | 10014573 | — |
| K26-085/1 | 85 | 12 | 35 | 7.1 | 6 | 15.5 | NB9001 | 10014576 | — |
| K26-090 | 90 | 12 | 35 | 7.1 | 6 | 15.5 | NB9001 | 10014579 | — |
| K26-095 | 95 | 12 | 35 | 7 | 6 | 15.5 | NB9001 | 10014581 | — |
| K26-100 | 100 | 12 | 35 | 7.1 | 6 | 15.5 | NB9001 | 10014583 | — |
| K26-110 | 110 | 12 | 40 | 7 | 6 | 15.5 | NB9001 | 10014589 | — |
| K26-115 | 115 | 20 | 30 | 7 | 6 | 15.5 | NB9001 | 10014591 | — |
| K26-120 | 120 | 20 | 40 | 9 | 8 | 15.5 | NB9001 | 10014597 | — |
| K26-125 | 125 | 20 | 40 | 9 | 8 | 15.5 | NB9001 | 10014601 | — |
| K26-125/1 | 125 | 30 | 40 | 9 | 8 | 15.5 | NB9001 | 10014604 | — |
| K26-125/2 | 125 | 30 | 50 | 9 | 8 | 15.5 | NB9001 | 10014606 | — |
| K26-130 | 130 | 20 | 40 | 9 | 8 | 15.5 | NB9001 | 10014611 | — |
| K26-140 | 140 | 20 | 40 | 11 | 10 | 15.5 | NB9001 | 10014617 | — |
| K26-145 | 145 | 20 | 45 | 11 | 10 | 15.5 | NB9001 | 10014620 | — |
| K26-145/1 | 145 | 41 | 45 | 11 | 10 | 15.5 | NB9001 | 10014622 | — |
| K26-150 | 150 | 20 | 40 | 11 | 10 | 15.5 | NB9001 | 10014625 | — |
| K26-160 | 160 | 20 | 40 | 11 | 10 | 15.5 | NB9001 | 10014631 | — |
| K26-175 | 175 | 20 | 40 | 11 | 10 | 15.5 | NB9001 | 10014637 | — |
| K26-180 | 180 | 20 | 40 | 11 | 10 | 15.5 | NB9001 | 10014640 | — |
| K26-200 | 200 | 20 | 40 | 11 | 10 | 15.5 | NB9001 | 10014643 | — |
| K26-200/1 | 200 | 20.2 | 40 | 11 | 10 | 15.5 | NB9001 | 10014646 | — |
| K26-230 | 230 | 30 | 40 | 13 | 12 | 15.5 | NB9001 | 10014650 | — |
| K26-250 | 250 | 30 | 40 | 13 | 12 | 15.5 | NB9001 | 10014652 | — |
| K26-300 | 300 | 60 | 40 | 13 | 12 | 15.5 | NB9001 | 10014662 | — |
